Introduction: Metal Crusher can also be called scrap metal crusher, scrap metal crusher machine, can crusher or paint bucket crusher machine. Scrap metal crusher is a hot metal disposal machine in the metal recycling sector, and it can be used for crushing many materials such as Sprite can, Lulu can, Red Bull can, coke can as well as paint bucket and engine oil can.
Metal Crusher can also be called scrap metal crusher, scrap metal crusher machine, can crusher or paint bucket crusher machine. Scrap metal crusher is a hot metal disposal machine in the metal recycling sector, and it can be used for crushing many materials such as Sprite can, Lulu can, Red Bull can, coke can as well as paint bucket and engine oil can. The crushed materials are easy to be transported and carried and convenient to be fed for steel smelting and the feeding times can be reduced.
Features of Metal Crusher
1. The blade of metal crusher is made of high-alloy metal, with good crushing effect on any high hardness material.
2. The gear motor drive of scrap metal crusher can save electric quantity of 20% compared to that of other pop can crusher.
3. Scrap metal crusher enjoys smooth starting up with low noise, and foundations are installed.
4. Metal crusher machine has strong structure and squeezing stiffened plates.
5. Metal crusher machine can be equipped with conveyor belt and feeding equipment.
6. Omni-directional control buttons make your operation and control simpler, so the entire grinding process only needs one person.
Working principle of Metal Crusher
Our crusher is the core of modern crusher, he can very effectively give the car body, compact, loose adulterant broken into pieces for post processing. Enter waste by high speed rotating hammer head impact to pieces, this kind of impact continuous crushing make scrap into dense spheres until the size small enough to through the grille is provided in the size.
Structure of Metal Crusher
Metal Crusher is mainly composed of worm and gear, reducer, main case, main frame, combined helical tooth cutter, driving shaft, driven shaft, rack wheel and pinion. We can design and process the most suitable model according to the requirement and suggestions of the customers.
Henan Ling Heng Machinery scrap metal crusher use multiple protection measures to protect lining plate almost unbreakable, etc., so as to improve the reliability of equipment operation.
Technical Parameters of metal crusher
| Model | Feederopening(mm) | Outputsize (mm) | Power (KW) | capacity(T/H) | Weight (T) | Dimensions (LxWxH) |
| LHM-400 | 500*600 | 10-40 | 18.5 | 0.5-0.7 | 2.2 | 1720*660*1850 |
| LHM-800 | 700*800 | 10-50 | 30 | 1-1.2 | 3.6 | 1910*850*1990 |
| LHM-1000 | 900*1000 | 14-70 | 75 | 2.5-3 | 6.5 | 2000*1070*1990 |
| LHM-1200 | 1000*1200 | 20-60 | 90 | 3-3.5 | 10 | 2400*1090*2270 |
| LHM-1600 | 1200*1600 | 20-100 | 112 | 3.5-4.5 | 18 | 3240*1730*3630 |
| LHM-1800 | 1200*1800 | 20-120 | 132 | 4.5-5.5 | 24 | 3620*1910*3870 |
| LHM-2000 | 1200*2000 | 20-140 | 160 | 5.5-6.5 | 37 | 4140*2230*4279 |
